DS-H10 Scanstrut Horizontal Entry Cable Seal - 6-10mm
DescriptionScanstrut Horizontal Entry Cable Seal is for cables from 6-10mm wide and is produced from high impact plastic to create a water tight seal between your vehicle/machinery and electrical cables.
Our range of cabling solutions eliminates time-consuming, sub-standard routing of cables and messy sealant to achieve a 100% watertight installation for your vehicles cables every time. The tapered gland forms a watertight seal around cables and a closed-cell foam gasket between the housing and vehicle ensures a 100% watertight fitting. All fixings are 316 stainless steel to resist corrosion in outside environments and the housing is made from tough, impact resistant plastic with rounded edges to prevent catching.
Our solutions are the only guaranteed and proven watertight installation for all of your vehicle and machinery cable needs. The range provides waterproof cable routing and is produced from high impact plastic with options for 16mm to 40mm connectors, making it ideal for almost every installation.
Tapered bung forms watertight seal. All units are supplied with a closed-cell base seal - 100% waterproof. All models have been IPX6 and IPX7 tested and approved.
EASY AND RELIABLE INSTALLATION
Captive nuts make for easy assembly and also allow reliable repeat installations. Each unit supplied with both pre-drilled and blank inner seals to make your installation as easy as possible.
NO NEED TO REMOVE CABLE CONNECTORS
Split-seal option does not require connector removal during install.
MULTI-FUNCTIONAL HORIZONTAL DOME SHAPE
Aesthetic dome-shaped profile provides a stronger, impact-resistant design and outer dome provides additional water shield.
